SWITCH 16 CHANNEL WITH POE | HIKVISION

Description

• Network Parameters
• Ports16 × 10/100 Mbps PoE port,2 × 1 Gbps combo
• Port TypeRJ45 port,full duplex,MDIMDI-X adaptive
• StandardIEEE 802.3,IEEE 802.3u,IEEE 802.3x,IEEE 802.3ab,IEEE 802.3z
• High Priority PortsPorts 1 to 8
• Forwarding ModeStore-and-forward switching
• Working ModeStandard mode (default),Extend mode
• MAC Address Table16 K
• Switching Capacity7.2 Gbps
• Packet Forwarding Rate5.3568 Mpps
• Internal Cache4 Mbits
• PoE Power Supply
• PoE StandardIEEE 802.3af,IEEE 802.3at
• PoE Power PinEnd-span: 1/2(-), 3/6(+)Mid-span: 4/5(+), 7/8(-)

  8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)

• PoE PortPoE: Ports 1 to 16
• Max. Port Power30 W
• PoE Power Budget230 W
• Software Function
• Device MaintenanceSupport remote upgrade, default parameter restoration, logs viewing, basic network parameter configuration, import and export configuration, and time synchronization.
• General
• ShellMetal material, fan-free design
• Net Weight2.59 kg (5.71 lb)
• Gross Weight3.680 kg (8.11 lb)
• Dimensions (W × H × D)440.00 mm × 44.00 mm × 220.80 mm (17.32” × 1.73” × 8.69”)
• Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
• Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
• Operating Humidity5% to 95% (no condensation)
• Relative Humidity5% to 95% (no condensation)
• Power Supply100-240 VAC, 50/60 Hz, Max. 2.5 A
• Max. Power Consumption250 W
• Approval
• EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
• SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
• ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006)
